Cannot rectify at full resolution on Oak4 S

MatteoL

I cannot run a simple pipeline that rectifies the frames from the main camera at full (48MP) resolution. I successfully rectified the image with the provided calibration data from the device at 1920×1080 and 3840×2160, but running the same pipeline at resolutions 2000×1500, 4000×3000, or 8000×6000 provides the following artefact with no errors:

Could you help me rectifying the image on the device side?

Here there is a MRE:

import cv2
import depthai as dai
import numpy as np
from numpy.typing import NDArray
from dataclasses import dataclass


@dataclass
class PoseData:
    resolution: tuple[int, int]
    pose: NDArray
    roi: tuple[int, int, int, int]


@dataclass(frozen=True)
class LensCalibrationData:
    # Camera intrinsic matrix
    intrinsics: NDArray[np.float64]
    # Distortion coefficients
    distortion: NDArray[np.float64]
    # Resolution at calibration
    resolution: tuple[int, int]

    @classmethod
    def from_luxonis(cls, calib_data: dai.CalibrationHandler, camera_socket: dai.CameraBoardSocket,
                     target_size: tuple[int, int] = None):
        if target_size is not None:
            width, height = target_size
            intrinsics = calib_data.getCameraIntrinsics(camera_socket, resizeWidth=width, resizeHeight=height)
        else:
            intrinsics, width, height = calib_data.getDefaultIntrinsics(camera_socket)

        assert calib_data.getDistortionModel(camera_socket) == dai.CameraModel.Perspective

        return cls(
            intrinsics=np.array(intrinsics),
            distortion=np.array(calib_data.getDistortionCoefficients(camera_socket)),
            resolution=(width, height)
        )


def get_rectification_map(calibration_data: LensCalibrationData, alpha=0):
    intrinsics, distortion = calibration_data.intrinsics, calibration_data.distortion

    mtx, roi = cv2.getOptimalNewCameraMatrix(intrinsics, distortion, calibration_data.resolution, alpha,
                                             calibration_data.resolution)

    map_x, map_y = cv2.initUndistortRectifyMap(intrinsics, distortion, np.eye(3), mtx, calibration_data.resolution,
                                               cv2.CV_32F)

    return map_x, map_y, mtx, roi


def get_mesh(calibration_data: LensCalibrationData, alpha=0):
    map_x, map_y, mtx, roi = get_rectification_map(calibration_data, alpha)

    # CELL_SIZE = 16
    CELL_SIZE = 64
    assert map_x.shape == map_y.shape

    overextension0, overextension1 = map_x.shape[0] % CELL_SIZE, map_x.shape[1] % CELL_SIZE
    if overextension0 != 0 or overextension1 != 0:
        map_x = map_x[:map_x.shape[0] - overextension0, :map_x.shape[1] - overextension1]
        map_y = map_y[:map_y.shape[0] - overextension0, :map_y.shape[1] - overextension1]

    m = np.empty((map_x.shape[0] // CELL_SIZE, 2 * (map_x.shape[1] // CELL_SIZE)))
    m[:, ::2] = map_x[::CELL_SIZE, ::CELL_SIZE]
    m[:, 1::2] = map_y[::CELL_SIZE, ::CELL_SIZE]

    return m, PoseData(calibration_data.resolution, mtx, tuple(roi))


def _warp_mesh(rectify: dai.node.Warp, mesh: NDArray):
    mesh_width = mesh.shape[1] // 2
    mesh_height = mesh.shape[0]
    mesh.resize(mesh_width * mesh_height, 2)

    assert len(mesh.shape) == 2 and mesh.shape[1] == 2
    rectify.setWarpMesh([dai.Point2f(p[0], p[1]) for p in mesh], mesh_width, mesh_height)


# 1280*720@120fps,1920*1080@60fps,2000*1500@50fps,3840*2160@20fps,4000*3000@14fps,8000*6000@3fps
# https://www.arducam.com/downloads/datasheet/B0478_48MP_IMX586_USB3.0_Camera_Datasheet.pdf

FULL_RES = (8000, 6000)  # 48MP
LOW_RES = (3840, 2160)

RESOLUTION = LOW_RES  # FULL_RES does not work

with dai.Device() as device:
    print(f'Camera {device.getProductName()}, MXID {device.getDeviceId()}')
    print(f"IMU type: {device.getConnectedIMU()}, firmware version: {device.getIMUFirmwareVersion()}")

    mesh, pose = get_mesh(
        LensCalibrationData.from_luxonis(device.readCalibration(), dai.CameraBoardSocket.CAM_A, RESOLUTION), 1)

with dai.Pipeline() as pipeline:
    camera = pipeline.create(dai.node.Camera).build()

    camera_output = camera.requestOutput(size=RESOLUTION, type=dai.ImgFrame.Type.GRAY8)

    rectify = pipeline.create(dai.node.Warp)
    rectify.setInterpolation(dai.Interpolation.BILINEAR)
    _warp_mesh(rectify, mesh)

    rectify.setOutputSize(RESOLUTION)
    rectify.setMaxOutputFrameSize(2 * RESOLUTION[0] * RESOLUTION[1])
    camera_output.link(rectify.inputImage)

    output_queue = rectify.out.createOutputQueue()

    cv2.namedWindow("Image", cv2.WINDOW_NORMAL | cv2.WINDOW_KEEPRATIO)

    pipeline.start()
    while pipeline.isRunning():
        message: dai.ImgFrame = output_queue.get()
        frame = message.getCvFrame()
        assert message.getType() == dai.ImgFrame.Type.GRAY8

        print(f'Resolution: {message.getWidth()}x{message.getHeight()}')
        cv2.imshow("detections", frame)
        if cv2.waitKey(1) == ord("q"):
            break

jakaskerl

MatteoL
Use commit aaf13981709835182f55cf97a8afabb828eaae81 from the develop branch and install using install_requirements.py. Should work, just tested it myself. Very slow though, but that is expected.

Thanks,
Jaka

MatteoL

After upgrading the Python library to depthai v3.0.0rc4, I successfully obtained the rectified images at 48 MP through requestOutput([…], enableUndistortion=True). However, by setting RESOLUTION = FULL_RES I still receive artifacts from the above MRE. The only reason left to manually introduce the warp node is to specify the alpha parameter as in the method getOptimalNewCameraMatrix of OpenCV.

Do you know how I can set a custom alpha in the DepthAI camera node? Do you confirm that the warp node does not behave correctly at resolutions 2000×1500, 4000×3000, and 8000×6000?

Thanks,
Matteo
